Replacing the Component Bay Cover
1. Reinsert the component bay cover by placing it on the bottom case assembly, and
make sure the case markers line up
.
2. Apply downward pressure and sliding the cover in the direction of arrow .
3. Replace screws & ( Figure 6 - 2 on page 6 - 4 ) and battery (see page 6 - 3 ).
Figure 6 - 3
Replacing the
Component Bay
Cover
