Board and Pin Assignments
2.5
Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
Description
CN1
20-pin Board to Board Connector
CN2
40-pin Board to Board Connector
CN3
Fan Power Connector
CN4
SMBus Connector
CN6
Power LED Header
CN7
External Speaker and Internal Buzzer Header
CN8
LVDS Connector
CN9
SATA Power Connector
CN10
Inverter Connector
CN11
DC Power Connector
CN12
VGA Connector
LAN1
Ethernet Port
SATA1
SATA Connector
BAT1
CMOS Battery Connector
SCN1
Full-size PCI-Express Mini Card and mSATA Connector
SCN2
SIM Card Slot
SCN3
Half-size PCI-Express Mini Card Connector
SSODIMM1
DDR3L SO-DIMM Socket
