www.desatech.com 113109-01G 31
PARTS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 29 of this manual.
VYGF33NRC VYGF33PRC
KEY
NO.
PART NO. DESCRIpTION QTY.
1a 122081-04 Back Log • • 1
1b 122081-05 Front Log • • 1
1c 122081-06 Crossover Log • • 1
2 103778-01 ODS Pilot • 1
103779-01 ODS Pilot • 1
3 098249-01 ODS Nut • • 2
4 099387-09 Pilot Tube • 1
100609-01 Pilot Tube • 1
5 104229-02 Burner Outlet Tube • 1
104229-01 Burner Outlet Tube • 1
6 111124 -01 Burner Retainer Spring • • 1
7 099056-19 Burner Orifice Injector • 1
099056-26 Burner Orifice Injector • 1
8 102772-01 Burner • • 2
9 M11084-38 Screw, #8 x 0.38 • • 2
10 104236-01DD Painted Base Assembly • • 1
11 M12461-26 Screw, #10 x 0.32 • • 4
12 ** Firebox Bottom • • 1
13 103284-03 Wiring Harness • • 1
14 098265-02 Elbow, Male • • 1
15 103782-01 Valve Bracket • • 1
16 103781-02 Gas Control Valve • 1
103781-01 Gas Control Valve • 1
17 098271-03 Ignitor Cable • • 1
18 102445-01 Piezo Ignitor • • 1
19 098304-01 Screw • • 7
20 099998-01 Switch • • 1
21 104241-01 Remote Switch Bracket • • 1
22 103587-01CK Switch Plate • • 1
23 097809-02 Male Connector • • 1
24 101628-03 Flexible Connector (Hose) • • 1
25 M50104-02 Bushing • • 1
26 M11084-26 Screw, #10 x 0.38 • • 4
27 901063-01 93/8" Flare x 1/2" NPT • • 1
28 099918-02 Pilot Regulator (Natural Only) • 1
29 099387-07 Pilot Tube (Valve to Regulator) • 1
pARTS AvAILABLE — NOT SHOWN
097555-01 Caution Decal • • 1
** Not a field replaceable part.
