4.2 Printer Function
1. Select the PC interface connected with bar code printer.
2. Click the “Printer Function” button to setup.
3. The detail functions in the Printer Function Group are listed as below.
Function Description
Calibrate Sensor
Calibrate the sensor specified in the Printer Setup
group media sensor field
Ethernet Setup
Setup the IP address, subnet mask, gateway for
the on board Ethernet
RTC Setup Synchronize printer Real Time Clock with PC
Print Test Page Print a test page
Reset Printer Reboot printer
Factory Default
Initialize the printer and restore the settings to
factory default.
Dump Text To activate the printer dump mode.
Ignore AUTO.BAS Ignore the downloaded AUTO.BAS program
Configuration Page Print printer configuration
Password Setup Set the password to protect the settings
The factory default settings are listed as below.
Parameter Default setting
Speed 203dpi: 5 IPS (127 mm/sec)
300dpi: 3 IPS (76.2 mm/sec)
Density 8
Label width 4.00” (101.6 mm)
Label height 4.00” (101.6 mm)
Sensor type Gap sensor
Gap setting 0.12” (3.0 mm)
Print direction 0
Reference point 0,0 (upper left corner)
Offset 0
Print mode Batch mode
Serial port settings 9600 bps, none parity, 8 data bits, 1 stop bit
Code page 850
Country code 001
Clear flash memory No
