18
3. Move the label roll guard horizontally to the
end of label spindle then flip down the label
roll guard.
4. Place the roll of media on the label supply spindle. Flip up the label roll guard.
Note:
When insert the 3 inch core adapter to the spindle, please making sure the arrow direction is as
following fig. When using 1 inch core media, please remove the 3 inch core adapters from the label
supply spindle.
3 inch media core 1 inch media core
