3.1.1-2.16 Left Position:
42
This option is used to adjust print position horizontally on the label. Press the button
to move the cursor from left digit to right digit, and press the button to set the value
from “+” to “-” or “0” to “9”. Press the button to set the value into printer. Press
key to cancel the setting and return to the previous menu. The default value is
+0000 and range is -9999 to +9999 dots.
3.1.2 Sensor
Sensor
Exit Status Calibration
3.1.2.1 Status
This function is available to check the printer’s sensor status. When enter the [Status] option, you
will see following message.
Print Setup 16/17
Head Close
Label Top
> Left Position
Left Position
+0000
Paper Len. 812
Gap Size 24
Intensity 3
Ref. Level 512
