American Energy Systems Crossfire Flex - Manual (Page 16)

Version 4.0 16
air to the stove to intensify the flame. You must establish a strong, intense burn
before corn can be fed into stove. (this process takes approx.15-20 minutes)
6. SYSTEM START Upon establishing an intense hot fire in the Burn-Pot, press and
hold the “ON/OFF” button on the control board for approx. 5 seconds. The (red)
light next to the igniter symbol will change from slow to fast flash, then release
button. If the stove is at the proper temperature, the operational sequence will
begin automatically. (If it does not, see guide on back of this sheet) The stove will
start up in heat setting #3. Allow adequate burn time for stove to heat up and
stabilize prior to temperature setting change. (approx. 30 min.) Adjust the inlet air
control as required to sustain even continuous burn.
FIGURE 3
OPERATING REFERENCE GUIDE
CROSSFIRE – FLEX STOVE (SEE FIGURE #3)
• DO NOT use any other ignition accelerant other than igniter/burn gel or igniter
blocks to start or enhance the fire in the Crossfire stove.
On/Off Button
Combustion
Air Control
