American Energy Systems MagnuM T40 User Manual
Page 2
2
TABLE OF CONTENTS
TECHNICAL BULLETIN: IMPORTANCE OF FRESH AIR
PAGE
3
AVENT TECHNICAL DATA / ESTIMATED FUEL FEED RATE CHART……………….
4
INTRODUCTION
&
SPECIFICATIONS………….……………………………………….... 5
SAFETY
STEPS
……………………………………………………………………………... 6
BURNING
SOLID
FUELS
(WOOD
PELLETS)………………………...................................
7
UNPACKING
YOUR
AVENT
WOOD
PELLET
STOVE
/
FLOOR
PROTECTION
/
CLEARANCES
TO
COMBUSTIBLES………………………………………………………
8
GUIDELINES
FOR
EXHAUST
VENTING
SYSTEMS
DESIGN……………..………......... 9-11
DESIGN
GUIDELINES
FOR
OUTSIDE
COMBUSTION
AIR
CONNECTION………….... 12-13
INSTALLATION
CONFIGURATIONS
/
MOBILE
HOME
INSTALLATION
REQ………. 14
ALCOVE
/
FREE
STANDING
STOVE
INSTALLATION
REQUIREMENTS…………….. 15-17
GLASS
MAINTENANCE,
ADJUSTMENT,
REMOVAL
AND
REPLACEMENT………… 17
CLEANING
THE
GLASS
/
STOVE
CONTROLS…………………………………………… 18-19
PRIMING
/
LIGHTING
/
OPERATING
INSTRUCTIONS………………………………….. 20
CIRCUIT
BOARD
FUNCTIONS
/
SETTING
THE
DRAFT………………………………… 21
MAINTENANCE
INSTRUCTIONS…………………………………………………………. 22
SPECIAL
CLEANING
/
OPERATIONAL
INSTRUCTIONS……………………………….. 23
AUTOMATIC
SAFETY
FEATURES………………………………………………………... 24
THERMOSTAT
INSTALLATION
/
OPTIONS……………………………………………... 25-26
12
VOLT
DC
WIRING
INSTALLATION…………………………………………………… 27
TROUBLE
SHOOTING
GUIDE……………………………………………………………... 27-29
REPLACEMENT
PARTS
LIST……………………………………………………………… 29
WIRING
DIAGRAM
/
CIRCUIT
BOARD
FINE
TUNE
ADJUSTMENTS…………………. 30
WARRANTY
INFORMATION……………………………………………………………… 31
SERVICE
RECORD………………………………………………………………………….. 32
WARRANTY
REGISTRATION
CARD……(IN
HARDWARE
PACKET)
