American Energy Systems BC7000 Auger Housing User Manual
Page 8
F:\AESBusinessSystems\AES Technical\Piece part instructions\BC7000 Auger Housing
Assembly.doc
• Press down on the top to compress the gasket.
• Align the mounting holes in the top with the main body sides and rear panel back.
• Attach using 2 #10-tek screws.
•
Confirm gasket is compresses all
around
• Attach the top to the back panel using 5- #8 tek
screws. Make sure top lid is level as shown.
One person
pressing down
while the other
person inserts
the screws
Top
Gasket compressed by top
