• Apply RTV to the back of removable air shell in an S Pattern.
• First attach the larger insulation piece across the top of the rear air shell.
• Second, attach the lower insulation piece
• Align the seams with no overlap or gaps
• Use flat plate to apply even pressure across insulation. This makes the RTV flow into the
fiberglass and promotes good adhesion
• Inspect the housing area where the hopper attaches for residual RTV or other material
that will interfere with the how the hopper sits on the auger housing. Remove as required
Large piece
across the
top
Smaller
piece across
the bottom
