7.5 PCI Configuration Space Map
Bus # Device # Function # Routing Description Notes
00h 00h 00h N/A Host Bridge (1)
00h 01h 00h N/A Host Bridge (1)
00h 02h 00h Internal Intel Integrated Graphics Device(1)
00h 03h 00h Internal Intel Video controller (1)
00h 17h 00h Internal PCIE Port #0 (1)
00h 18h 00h Internal PCIE Port #1 (1)
00h 19h 00h Internal PCIE Port #2 (1)
00h 1Ah 00h Internal PCIE Port #3 (1)
00h 1Bh 00h Internal Intel HD Audio Device (1)
00h 1Fh 00h Internal Intel LPC Interface Bridge (1)
01h 00h 00h Internal Intel PCI to PCI Bridge (2)
02h 00h 00h Internal Intel EG20T Packet Hub Controller (2)
02h 00h 01h Internal Intel EG20T Ethernet Controller (2)
02h 00h 02h Internal Intel EG20T GPIO Controller (2)
02h 02h 00h Internal Intel EG20T OHCI USB Controller (2)
02h 02h 01h Internal Intel EG20T OHCI USB Controller (2)
02h 02h 02h Internal Intel EG20T OHCI USB Controller (2)
02h 02h 03h Internal Intel EG20T EHCI USB Controller (2)
02h 02h 04h Internal Intel EG20T USB Client (2)
02h 04h 01h Internal Intel EG20T SDIO #0 Controller (2)
02h 04h 02h Internal Intel EG20T SDIO #1 Controller (2)
02h 06h 00h Internal Intel EG20T SATA AHCI Controller (2)
02h 08h 00h Internal Intel EG20T OHCI USB Controller (2)
02h 08h 01h Internal Intel EG20T OHCI USB Controller (2)
02h 08h 02h Internal Intel EG20T OHCI USB Controller (2)
02h 08h 03h Internal Intel EG20T EHCI USB Controller (2)
02h 0Ah 00h Internal Intel EG20T Shared DMA Controller (2)
02h 0Ah 01h Internal Intel EG20T UART Controller (2)
02h 0Ah 02h Internal Intel EG20T UART Controller (2)
02h 0Ah 03h Internal Intel EG20T UART Controller (2)
02h 0Ah 04h Internal Intel EG20T UART Controller (2)
02h 0Ch 00h Internal Intel EG20T Shared DMA Controller (2)
02h 0Ch 01h Internal Intel EG20T SPI Controller (2)
02h 0Ch 02h Internal Intel EG20T I2C bus Controller (2)
02h 0Ch 03h Internal Intel EG20T CAN bus Controller (2)
02h 0Ch 04h Internal Intel EG20T IEEE1588 Controller (2)
(1) These devices are from the CPU.
(2) These devices are from the PCH EG20T.
