Row B
Signal Descriptions (cont’d)
XXX Strikethrough pin names indicates that the signal is not supported on this module.
Pin
Signal
Description
Type
PU/PD
Comment
B1
GND(FIXE D)
Ground
PWR
-
-
B2
GBE0_ ACT#
E thernet Activity LE D
OD
-
-
B3
LPC _FRAME #
LPC Frame Indicator
O-3.3
-
-
B4
LPC_ AD0
LPC multiplexed Adress & DATA Bus
IO-3.3
-
-
B5
LPC_ AD1
LPC multiplexed Adress & DATA Bus
IO-3.3
-
-
B6
LPC_ AD2
LPC multiplexed Adress & DATA Bus
IO-3.3
-
-
B7
LPC_ AD3
LPC multiplexed Adress & DATA Bus
IO-3.3
-
-
B8
LP C_DR Q0#
LPC Serial DMA Request 0
I-3.3
-
not supported
B9
LP C_DR Q1#
LPC Serial DMA Request 1
I-3.3
-
not supported
B10
LPC_ CLK
LPC Clock
O-3.3
-
-
B11
GND(FIXE D)
Ground
PWR
-
-
B12
PWRBTN#
P ower Button
I-3.3
PU 10K 3.3Vsb
-
B13
S MB_C K
S MBus Clock
IO-3.3
PU 2k2 3.3Vsb
-
B14
SMB_DAT
S MBus Data
IO-3.3
PU 2k2 3.3Vsb
-
B15
SMB_ALE RT#
S ystem Management Bus Alert for S MI
I-3.3
PU 10k 3.3V
B16
SATA1_TX+
S ATA 1 Transmit Data +
O - DP
-
-
B17
SATA1_TX-
S ATA 1 Transmit Data -
O - DP
-
-
B18
SUS _STAT#
Imminent suspend operation inidcator
O-3.3
-
not supported
B19
SATA1_RX+
S ATA 1 Receive Data +
I - DP
-
-
B20
SATA1_RX-
S ATA 1 Receive Data -
I - DP
-
-
B21
GND(FIXE D)
Ground
PWR
-
-
B22
RSVD
NC
-
-
B23
RSVD
NC
-
-
B24
PWR_OK
P ower OK from main power supply
I-3.3
-
always reserve pull up
B25
RSVD
NC
-
-
B26
RSVD
NC
-
-
B27
WDT
Watch Dog Event occurred indicator
O-3.3
PU 10K 3.3Vsb
B28
AC/HDA_SDIN2
S erial TDM data input 2
I-3.3
-
not supported
B29
AC/HDA_SDIN1
S erial TDM data input 1
I-3.3
-
-
B30
AC/HDA_SDIN0
S erial TDM data input 0
I-3.3
-
-
B31
GND(FIXE D)
Ground
PWR
-
-
B32
SP KR
Output for audio enunciator (P C Beep)
O-3.3
-
-
B33
I2C_CK
General purpose I2C port clock output
IO-3.3
PU 4k7 3.3V
B34
I2C_DAT
General purpose I2C port data I/O line
IO-3.3
PU 4k7 3.3V
B35
THRM#
Off module over temperature indicator
I-3.3
PU 1k2 3.3V
-
B36
US B7-
US B Data - P ort7
I/O - DP
-
client port
B37
US B7+
US B Data + Port7
I/O - DP
-
client port
B38
USB_4_5_ OC#
US B OverC urrent P ort 4,5
I-3.3
PU 10k 3.3Vsb
-
B39
US B5-
US B Data- Port5
I/O - DP
-
-
B40
US B5+
US B Data+ Port5
I/O - DP
-
-
B41
GND(FIXE D)
Ground
I-3.3
-
-
B42
US B3-
US B Data- Port3
I/O - DP
-
-
B43
US B3+
US B Data+ Port3
I/O - DP
-
-
B44
USB_0_1_ OC#
US B OverC urrent P ort 0,1
I-3.3
PU 10k 3.3Vsb
-
B45
US B1-
US B Data- Port1
I/O - DP
-
-
B46
US B1+
US B Data+ Port1
I/O - DP
-
-
B47
E XCD1_PE RST#
P CI Express Card Reset signal
O-3.3
-
not supported
B48
E XCD1_C PPE #
P CI Express capable card request
O-3.3
-
not supported
B49
SYS_ RE S E T#
Reset Button Input I-3.3
none
3.3Vsb
B50
CB_ RE S E T#
Reset output from Module to C arrier Board
O-3.3
-
-
B51
GND(FIXE D)
Ground
PWR
-
-
B52
RSVD
NC
-
-
B53
RSVD
NC
-
-
B54
GPO1
GP O1 or S DIO contr. 0 Command/R esponse
IO-3.3
PU 10k 3.3V
BIOS select
B55
RSVD
NC
-
-
