nanoX-TC User’s Manual

Page 28

APIC Mode (cont’d)

IRQ#

Typical Interrupt Resource

Connected

Available

15 N/A

N/A

No

16

N/A

PCI-E Slot #0, 1, 2, 3, VGA controller,

Yes (2)

High Definition Audio controller,
USB controller #1,2,3, Gigabit Ethernet,
I2C controller, IEEE1588 controller,
GPIO controller, CAN controller,
EHCI controller #1

17 N/A

SATA

AHCI

controller

Yes

(2)

18

N/A

SD Host controller #1, 2

Yes (2)

19

N/A

USB controller #4, 5, 6,

Yes (2)

USB Client Controller,
UART controller,
EHCI controller #2,
EG20T DMA controller #1

20 N/A

N/A

Yes

21 N/A

N/A

Yes

22 N/A

N/A

Yes

23 N/A

N/A

Yes

(1) These IRQs can be used for PCI devices when onboard device is disabled.

(2) These devices from are from the PCH EG20T.
