nanoX-TC User’s Manual Page 10
2.7 SDIO/MMC Extension
Chipset: Integrated in Intel® Controller Hub
Type: Single port SDIO/MMC supports SDIO specification 1.1 and MMC specification 4.0
Connection: Multiplexed over GPIO signals to carrier
2.8 Operating Systems
Standard Support
- Windows
7
- Linux 2.6.x
Extended Support (BSP)
- Linux
BSP
- AIDI I2C Library for Windows and Linux
- WinCE 6.0 / 7.0
- Windows XP Embedded
2.9 Mechanical and Environmental
Standard Operating Temperature: 0°C to 60°C
Relative Humidity: up to 90% at 55°C
Form Factor and Type: PICMG COM.0, COM Express ™ Type 10 compatible
Dimensions: 85 x 55 mm
2.10 Power Specifications
Input Power: 4.75 V – 21 V wide range, supports AT mode and ATX mode
(with additional 5 Vsb)
Power States: Supports S0, S3, S4, S5
Power Consumption: 6W at 5V typical, 5W idle
Smart Battery Support: Yes
