5 Pinout and Signal Descriptions
5.1 COM Express
™
Type 10 Pinout
All pinouts on AB connector of the nanoX-TC comply with pin-out and signal descriptions
used in the “PICMG
®
COM.0 R2.0: COM Express
®
Module Base Specification Type 2”.
This chapter details pinouts, signal descriptions, and mechanical characteristics of the
nanoX-TC.
An additional document, the “PICMG COM Express Design Guide” gives a general
introduction to carrier board designs for COM Express
™
modules.
The above function mappings are a generic description of COM Express pinouts,
and not necessarily supported on the module described in this manual.
55
.
84
.
AB
.
95
.
.
125
.
95
Dimensions in mm
- Gigabit Ethernet port
- LPC interface
- 4 Serial ATA channels
- AC'97 or High Definition Audio
- 6 USB 2.0 ports
- 6 PCI Express x1 Lanes
- Dual 24-bit LVDS channels
- SDVO
- GPIO / SDIO
- Keyboard
- I
2
C / SMBus
-SPI support
- Primary power input: +12V,
+5V standby and 3.3V RTC
AB Connector
