Board Interfaces 37
VPX6000
Table 4-7: tBP-VPX6000 Signal Routing Table
Signal Connection to/from
USB 3.0 Slot5
USB 2.0 Slot5
HDMI Slot5
DVI Slot5
Gigabit Ethernet Slot1,2,5
SATA Slot5
XMC Slot5
InfiniBand Slot5
Line In Slot5 (Node A: CN69; Node B: CN72)
Line Out Slot5 (Node A: CN70; Node B:CN71)
IDT Switch Hub I2C Slot5
BIOS Select Slot5
COM Slot5
IPMC JTAG Slot5
VPX JTAG Slot5
Speaker Out Slot5
LPC Debug Port Slot5
VPX SM Slot5
IPMC UART Slot5
Keyboard / Mouse Slot5
Reset Button Slot5
Power Button Slot5
VPX J Slot 1-5
VPX RJ Slot 3,4
RTC and PSON Battery and ATX power connector
