10 Specifications
Note: Specifications are subject to change without prior notice.
Audio • Stereo audio, single-ended Line-in, Line-out to RTM (each
node)
Super IO ITE IT8783E/AX-L (each node)
• 2 Serial ports
• Keyboard/Mouse routed to RTM
BIOS • AMI® EFI BIOS, SPI flash memory
• Dual failover BIOS per node
Storage
(each node) • One 32GB SLC mode SATA flash by mezzanine card
• Three SATA 6Gb/s to rear P3/P4 ,P5/P6
Watchdog
Timer • System Reset and NMI, with programmable interval via
IPMC
GPIO • 8 GPIO pins per node routed to RTM
Miscellaneous • Front panel LEDs: CPU, PCH, RAM, P12V, P5V Power
Good, Port 80
• Recessed reset button
Mechanical • Dimensions: 233.35 mm x 160 mm (0.85" pitch)
• Weight: 1407.3 g
Environmental • Operating Temperature:
ETT (R2): -40°C to +75°C air cooled
CC 1 (R1): -40°C to +75°C conduction cooled
CC 2 (R2): -40°C to +85°C conduction cooled
• Storage Temperature: -50°C to 100°C
• Humidity: 95%, non-condensing
• Shock:
ETT (R2): 20g peak, 11ms
CC 1/2 (R1/R2): 40g peak, 11ms
• Vibration:
ETT (R2): Random: 0.002G2/Hz, 10~2000Hz; Sine: 2G
5~500Hz
CC 1/2 (R1/R2): Random: 0.1G2/Hz, 15~2000Hz;
12Grms (MIL-STD-810F Fig 514.4-8 for aircraft)
• Conformal Coating:
ETT (R2): optional
CC 1/2 (R1/R2): default
Operating
Systems • Microsoft Windows 7 32/64-bit
• Red Hat Enterprise Linux
• Wind River VxWorks 6.9.3
EMI • CE/FCC Class A
Table 2-1: VPX6000 Blade Specifications
