Board Interfaces

17

VPX6000

4

Board Interfaces

4.1

VPX6000 Board Layout

Figure 4-1: VPX6000 Board Layout - Top View

Figure 4-2: VPX6000 Front IO

Node A

CPU

Node B

CPU

Node A

PCH

Node B

PCH

Node A

USB 3.0

Node A

VGA

Node A

GbE RJ45

IDT Switch

Super I/O

P0

P1

P2

P3

P4

P5

P6

Node A

XDP

Node B

XDP

SATA SSD

B2B connector

Node A

DDR3L-1600

ECC

Node B

DDR3L-1600

ECC

Node B

VGA

Node B

GbE RJ45

Node B

USB 3.0

10GbE

Quad GbE
