Table 4-3, P3 connector signal descriptions – ADLINK VPX6000 User Manual

Page 40

background image

28

Board Interfaces

Table 4-3: P3 Connector Signal Descriptions

Signal

I/O

Description

NA_REAR-RX[P/N]1

I

Node A PCIe port1 receive LAN from backplane to PCH

NA_REAR-TX[P/N]1

O

Node A PCIe port1 transmit LAN from PCH to backplane

NA_REAR-RX[P/N]2

I

Node A PCIe port2 receive LAN from backplane to PCH

NA_REAR-TX[P/N]2

O

Node A PCIe port2 transmit LAN from PCH to backplane

NA_REAR_GPIO[0:7]

I/O

Node A General Purpose IO, Channels 0-7

NA_USB3_RX_2[P/N]

I

Node A USB 3.0 port receive lane from backplane to PCH

NA_USB3_TX_2[P/N]

O

Node A USB 3.0 port transmit lane from PCH to backplane

NA_USB3_RX_5[P/N]

I

Node A USB 3.0 port receive lane from backplane to PCH

NA_USB3_TX_5[P/N]

O

Node A USB 3.0 port transmit lane from PCH to backplane

NA_RTM_BOOT#

I

Node A boot up from RTM BIOS when this pin pull low

NA_EXT_NODE_RST

I

Node A reset input

NA_SATA_RX[P/N]3

I

Node A SATA 6Gb/s port receive lane from backplane to PCH

NA_SATA_TX[P/N]3

O

Node A SATA 6Gb/s port transmit lane from PCH to backplane

NA_SPI_*

I/O

Node A SPI bus for RTM BIOS

NA_LPC_*

I/O

Node A LPC bus for RTM debug port

NA_MSCLK

I/O

Node A PS2 bus mouse signal clock

NA_MSDATA

I/O

Node A PS2 bus mouse signal data

NA_KBCLK

I/O

Node A PS2 bus keyboard signal clock

NA_KBDATA

I/O

Node A PS2 bus keyboard signal data

PROG_*

I/O

IPMC JTAG PORT

REAR_LANSW_UART_TX /

REAR_LANSW_UART_RX

I/O

COM port for GLAN Switch hub software develop

P12V

I

+12V Power source

P5V

I

+5V Power source
