26 Board Interfaces
Table 4-2: P2 Connector Signal Descriptions
Signal I/O Description
IPMI_PRG_RX /
IPMI_PRG_TX
I/O COM port for IMPC software develop
32NT8A_MSMBCLK /
32NT8A_MSMBDAT
I/O I2C port for PCIE Switch Hub software develop
PCIE_BP1_
[N/P]TX(3:0)
O PCIe channel A transmit lane from payload to backplane
PCIE_BP1_
[N/P]RX(3:0)
I PCIe channel A receive lane from backplane to payload
PCIE_BP2_
[N/P]TX(3:0)
O PCIe channel B transmit lane from payload to backplane
PCIE_BP2_
[N/P]RX(3:0)
I PCIe channel B receive lane from backplane to payload
PCIE_BP3_[
N/P]TX(3:0)
O PCIe channel C transmit lane from payload to backplane
PCIE_BP3_
[N/P]RX(3:0)
I PCIe channel C receive lane from backplane to payload
PCIE_BP4_
[N/P]TX(3:0)
O PCIe channel D transmit lane from payload to backplane
PCIE_BP4_
[N/P]RX(3:0)
I PCIe channel D receive lane from backplane to payload
