Board Interfaces 27
VPX6000
P3 Connector Pin Assignment
Pin A B C D E F G
1
NA_REAR
-RXP1
NA_REAR-R
XN1
GND
NA_REAR
-TXP1
NA_REAR-T
XN1
GND
NA_REAR
-RXP1
2 GND
NA_REAR-R
XP2
NA_REAR-
RXN2
GND
NA_REAR-T
XP2
NA_REAR
-TXN2
GND
3
NA_USB3_
RX_2P
NA_USB3_
RX_2N
GND
NA_USB3
_TX_2P
NA_USB3_T
X_2N
GND
NA_USB3
_RX_2P
4 GND NC NC GND
NA_RTM_
BOOT#
NA_EXT_
NODE_RST
GND
5
NA_SPI_SO_
C2
NA_SPI_
CS2#
GND
NA_SPI_
SI_C2
NA_SPI_
CLK_C2
GND
NA_SPI_S
O_C2
6 GND NA_MSCLK
NA_MSDA
TA
GND NA_KBCLK
NA_KB
DATA
GND
7
NA_LPC_
AD0
NA_LPC_
AD1
GND
NA_LPC_
AD2
NA_LPC_
AD3
GND
NA_LPC_
AD0
8 GND
NA_LPC_
FRAME-L
NA_CLK33
_DBC
GND NC
NA_PLTRS
T_BIOS-L
GND
9
NA_USB3_
RX_5P
NA_USB3_R
X_5N
GND
NA_USB3
_TX_5P
NA_USB3_T
X_5N
GND 9
10 GND
NA_SATA_R
XP3
NA_SATA_
RXN3
GND
NA_SATA_T
XP3
NA_SATA_
TXN3
10
11 PROG_TDI PROG_TDO GND
PROG_T
MS
PROG_JTA
G_VPX_TCK
GND 11
12 GND
PROG_TDO_
CTRL
NC GND NC NC 12
13 NC NC GND NC NC GND 13
14 GND NC NC GND NC NC 14
15
REAR_LANS
W_UART_TX
REAR_LANS
W_UART_RX
GND NC NC GND 15
16 GND P12V P12V GND P5V P5V 16
