• cPCIS-1000 Series Sub-systems
7.1 cPCIS-1151
7.1.1 Features
•
Standard 19” 3U CompactPCI form factor, 3U in height
•
Attached high brightness 6.4” TFT LCD for user interface display
•
Attached 175W Universal AC input power supply
•
Using cBP-3108P backplane with 32-bit CompactPCI bus
•
Accept 5 I/O slots due to the available front space
•
Comprehensive EMC shielding
7.1.2 Configurations
u Chassis: cPCIS-1000
u Backplane: cBP-3106P for 32-bit CompactPCI bus
u Power Supply: Installed 175W power supply cPS-150R
u LCD module: cPCI-LCD
u I/O slots configuration:
•
10-slot is installed with high brightness 6.4” TFT LCD
•
5-slot for I/O module
•
3-slot for system module
•
2-slot is installed with single 175W cPS-150R PSU
•
1-slot for power switch
•
An extra LCD controller card (cPCI-8215 or 8217) should be
installed
7.1.3 Ordering Options
To complete the system to work, you should order an optional LCD
controller card:
u
cPCI-8215: LCD controller card with C&T69000 and 2MB RAM
u
cPCI-8217: LCD controller card with SMI chipset and 8MB RAM
The slot-panels with EMC gasket for the front or rear I/O cards are optional
and not installed with this sub-system.
u
cPCI-SP3E: 3U slot-panel with EMC gasket for both front I/O or rear
I/O
