ADLINK cBP-3204[R] - Manual (Page 43)

Backplane
• 33
4.3 cBP-3200 Series
4.3.1 Features
u
Compliant to CompactPCI PICMG 2.0 R2.1 specifications
u
Support standard 3U form factor
u
32-bit CompactPCI bus on P1, support 7-bus mastering I/O slots
u
Optional P2 with rear I/O capability
u
Support ATX and screw terminals for DC power input connectors
u
V(I/O) selectable from +5V or +3.3V.
u 10 layers PCB for accurate impedance control
u Dimension: 133.35 mm x 182.0 mm x 3.2 mm (3U height, 9 -slot width)
4.3.2 Products List
•
cBP-3208: 8-slot, 3U 64-bit CompactPCI backplane
•
cBP-3206: 6-slot, 3U 64-bit CompactPCI backplane
•
cBP-3204: 4-slot, 3U 64-bit CompactPCI backplane
•
cBP-3208R: 8-slot, 3U 64-bit CompactPCI backplane with rear I/O
•
cBP-3206R: 6-slot, 3U 64-bit CompactPCI backplane with rear I/O
•
cBP-3204R: 4-slot, 3U 64-bit CompactPCI backplane with rear I/O
