Power Supply Unit
• 9
3
Power Supply Unit
The power supply unit in the 3U CompactPCI system is with modular design.
The users can chose the most suitable solution for the specified applications.
There are many kinds of power supply unit can be installed in 3U
CompactPCI card cage. In this chapter, the features and specifications of
the following power supply unit or modules are shown.
u Redundant Power Supply
•
cPS-150R: 3U 175W universal AC input redundant power supply
(31-pin)
•
cPS-175/AC: 3U 175W universal AC input redundant power supply
(47-pin)
•
cPS-175/48: 3U 175W –48V DC input redundant power supply
(47-pin)
•
cPS-175/24: 3U 175W –24V DC input redundant power supply
(47-pin)
u
PS2-size Power Supply
•
APS-925A: 280W Auto-switched AC input ATX Power Supply
