• LCD Kit
5.4 Connectors Pin Assignment
LCD Signal Connector on the LCD
Pin # Symbol Function Pin # Symbol Function
1 GND Ground 17 G4 Green Data Signal
2 CLK
Clock signal for sampling
image digital data
18 G5 Green Data Signal
3 Hsync Horizontal Sync Signal 19 GND Ground
4 Vsync Vertical Sync Signal 20 B0 Blue Data Signal
5 GND Ground 21 B1 Blue Data Signal
6 R0 Red Data Signal 22 B2 Blue Data Signal
7 R1 Red Data Signal 23 B3 Blue Data Signal
8 R2 Red Data Signal 24 B4 Blue Data Signal
9 R3 Red Data Signal 25 B5 Blue Data Signal
10 R4 Red Data Signal 26 GND Ground
11 R5 Red Data Signal 27 DENB
Signal to set horizontal
display position
12 GND Ground 28 VCC DC 5V power supply
13 G0 Green Data Signal 29 VCC DC 5V power supply
14 G1 Green Data Signal 30 R/L
Horizontal image shift
select
15 G2 Green Data Signal 31 U/D Vertical image shift select
16 G3 Green Data Signal --
LCD Signal Extension Connector for cPCI-8215
Signal Pin # Pin # Signal
+12V 1 2 +12V
GND 3 4 GND
VDD 5 6 VDD
ENVEE 7 8 GND
P0 9 10 P1
P2 11 12 P3
P4 13 14 P5
P6 15 16 P7
P8 17 18 P9
P10 19 20 P11
P12 21 22 P13
P14 23 24 P15
P16 25 26 P17
P18 (N/C) 27 28 P19 (N/C)
P20 (N/C) 29 30 P21 (N/C)
P22 (N/C) 31 32 P23 (N/C)
GND 33 34 GND
CLk 35 36 FLM
M 37 38 LP
GND 39 40 EN_BKL
GND 41 42 ENVDD
VDD 43 44 VDD
