Power Supply Unit
• 19
Temperature
Coefficient 0.05% / °C
Protection 1. All outputs protected against overload and short circuit. Straightline
current limiting, does not fold-back or latch-up during startup or load
transients. Automatic recovery.
2. Shutdown at internal heatsink temperature of 95°C. Automatic
recovery.
3. Shutdown at the output voltage exceeds the nominal voltage 20%.
Recycle power to reset.
Other
Item cPS-175/AC cPS-175/48 cPS-175/24
Output/Input
Connector Positronic
PCI47M400A1
Indicator Green LED indicating INPUT O.K.
Red LED indicating a power supply FAULT.
Switching
Frequency 100kHz
MTBF 100,000hr (by part counting MIL-HDBK0217E)
MTTR 5 Minutes (based on module replacement)
Safety TUV/VDE EN60950
UL
CE EMI: EN55022 Class A radiated and conducted
EMS:EN 50082-2 (IEC1000-4-2, IEC1000-4-4, IEC-4-5, IEC1000-4-11)
Shock &
Vibration Frequency range: 5Hz~35Hz (5 min); 35~55Hz (5 min); 55~5Hz(5 min)
Displacement: 0.38 mm
Dweep time: 30 mins for each axis (X,Y,Z) duration 2 cycles for the
three orthogonal axis
Insulation Primary –
Secondary: 3050Vrms
Primary – Chassis
Ground:3050Vrms
Secondary – Chassis
Ground:500Vrms Primary –
Secondary:1150Vrms
Primary – Chassis
Ground:500Vrms
Secondary – Chassis
Ground:500Vrms Primary –
Secondary:1150Vrms
Primary – Chassis
Ground:500Vrms
Secondary – Chassis
Ground:500Vrms
Output Insulation Floating & SELV
Operating
Temperature 0°C~ 70°C(the temperature on the chassis)
Full power from 0°C to 40°C with 15 cfm forced air flow
Storage
Temperature -10°C ~+85°C
Humidity < 95% @ 40°C
Altitude 6,400m
Dimension 40.0 (W)
×
128.5(H)
×
172.8(D) mm
Weight about 0.85kg
Note : minimal load 2 A @ +5V is required.
