cPCIS-2000 Series Sub-systems
• 49
6.1 cPCIS-2150 Series
•
cPCIS-2150 is without rear I/O connectors
•
cPCIS-2150R is with rear I/O connectors
6.1.1 Features
•
Standard 19” 3U CompactPCI form factor, 4U in height
•
Attached high brightness 6.4” TFT LCD for user interface display
•
Attached Auto-switched off-the-shelf 280W ATX power supply
•
Using cBP-3208 backplane with 32-bit CompactPCI bus
•
Accept 7 I/O slots and one system slot
•
Side handle design for portable instrument
•
Two built-in 50 CFM fans for self-cooling system
•
Removable fans and air-filter
•
Suitable for both rack-mount and desktop applications
•
Comprehensive EMC shielding
•
cPCIS-2150R is equipped with cBP-3208R and rear I/O card guides
for rear I/O applications
6.1.2 Configurations
u Chassis: cPCIS-2000A
u
Backplane:
•
cBP-3208 is for 32-bit CompactPCI bus without rear I/O connectors
•
cBP-3208R is for 32-bit CompactPCI bus with rear I/O connectors
u
Power Supply: 280W ATX power supply is installed with cPCI-PSF
u
LCD module: cPCI-LCD
u
I/O slots configuration:
•
10-slot is installed with high brightness 6.4” TFT LCD
•
7-slot for I/O module
•
3-slot for system module
•
1-slot spared
•
cPCI-PSF Power supply frame is installed behind the LCD
•
An extra LCD controller card (cPCI-8215 or 8217) should be
installed
