LCD Kit
• 47
LCD Signal Extension Connector for cPCI-8217
Signal Name
Pin #
Pin #
Signal Name
+12V
1
2
+12V
GND
3
4
GND
+5V
5
6
+5V
ENPVEE
7
8
GND
PD0
9
10
PD1
58
57
PD2
11
12
PD3
PD4
13
14
PD5
PD6
15
16
PD7
PD8
17
18
PD9
PD10
19
20
PD11
PD12
21
22
PD13
PD14
23
24
PD15
PD16
25
26
PD17
PD18 (N/C)
27
28
PD19 (N/C)
PD20 (N/C)
29
30
PD21 (N/C)
PD22 (N/C)
31
32
PD23 (N/C)
GND
33
34
GND
SHFCLK
35
36
FLM
M
37
38
LP
2
1
GND
39
40
ENABKL
GND
41
42
ENA VDD
VCC
43
44
+5V
NC
45
46
NC
PD24 (N/C)
47
48
PD25 (N/C)
PD26 (N/C)
49
50
PD27 (N/C)
PD28 (N/C)
51
52
PD29 (N/C)
PD30 (N/C)
53
54
PD31 (N/C)
PD32 (N/C)
55
56
PD33 (N/C)
PD34 (N/C)
57
58
PD35 (N/C)
Note: Only 44 pins are used. Pin #45 to pin #58 are no used.
Power and control connector for the backlight inverter
Pin #
Name
Color
1
+12V
Yellow
2
Power On (default connect to +5V)
Red
3
GND
Black
4
VR (default connect to GND)
Black
