ADLINK cPCI-6870 User Manual
Page 64
50
Getting Started
4. Press the DB-6920SAT adapter onto the board-to-board
connector until it is properly seated. Secure the adapter
to the board with the two screws provided.
5. Secure the hard drive with two screws from the solder
side of the board.
CAUTION:
Support the hard drive assembly when turning the board over
to proceed with step 5.
