4 Overview
1.4 Product List
Products included in the cPCI-6870 Series include:
Processor Blade
X cPCI-6870: 4HP width (single-slot) 6U CompactPCI blade fea-
turing single Intel® Core™2 Duo or Celeron® processor, dual
channel DDR3-800/1066 SDRAM via two SO-DIMM sockets,
two PMC/XMC sites, 2x USB, 2x GbE, RJ-45 COM/VGA*,
SATA, and CF socket
Rear Transition Modules
X cPCI-R6001P: 4HP width RTM with VGA, 2x COM, 3x USB,
2x GbE, PIM, SATA
X cPCI-R6002: 4HP width RTM with VGA, 2x COM, 3x USB,
2x GbE, SATA
X cPCI-R6002D: 8HP width RTM with VGA, 2x COM, 3x USB,
2x GbE, SATA, DB-R6000L2 riser card provides 2x USB,
KB/MS, Mic-in, Line-out and removable SATA direct connec-
tor (DB-6920SAT) for 2.5” SATA HDD
X cPCI-R6101: 4HP width RTM with 4x GbE, 4x USB, SATA,
VGA, PS/2 KB/MS, CF & SD sockets
X cPCI-R6111: 4HP width RTM with 2x GbE, 4x USB, SATA,
VGA, PS/2 KB/MS, CF, & SD sockets
X cPCI-R6201: 8HP width RTM with 2x GbE, 4x USB, 2x COM,
VGA, 2x SATA, Mic-in, Line-out, PS/2 KB/MS, 8x SAS
Adapter Kit
X DB-CF-SA: CompactFlash socket kit for cPCI-R6001D &
cPCI-R6201 RTMs, including DB-6920CF adapter board, card
guide and screws to replace SATA adapter with CompactFlash
socket
NOTE: NOTE:
* VGA is not supported on the front panel RJ-45 connector of models with
ordering numbers ending in “xx30” and higher. On these models, VGA is
directly routed to the RTM and the RJ-45 connector is a dedicated serial port.
