10 Specifications
2.2 I/O Connectivity Tables
Processor Blade
Table 2-1: SBC I/O Connectivity
Notes:
1. RJ-45 connector shared by COM port and VGA port. COM and
VGA cannot be used simultaneously. (VGA is not supported on the
front panel RJ-45 connector (CN11) of models with ordering num-
bers ending in “xx30” and higher.)
2. 2.5” HDD occupies the same space as the outer PMC/XMC
site and cannot be installed simultaneously.
Function
cPCI-6870
Faceplate Board
Gigabit Ethernet 2 —
COM1 1
(1)
(RJ-45) —
USB 2.0 2 —
PMC/XMC — 2
VGA 1
(1)
(RJ-45) —
Serial ATA — 1
(2)
Compact Flash — 1
Reset Button 1 —
