64 MotionCreatorPro 2
PCI-7856 
User’s Manual
Operation instructions:
A. Speed parameter of homing profile, please refer to the
figure of area F.
B. Modes setting of homing function, you can select one of
items in pull down menu
C. Command and position information when homing. After
the home is done, the command counter will be reset to
zero at the edge of ORG ON when VA speed.
D. Operation button for start homing or stop/abort homing
function
E. Motion and I/O status when homing
F. The timing chart of homing function
