Introduction 3
PCI-7856
User’s Manual
1.1 Specifications
PCI Bus
 PCI local bus specification Rev. 2.1-compliant
Master Controller
 Dedicated Motion Controller
 Motionnet ASIC master control (80 MHz external clock)

Dedicated I/O Controller

HSL ASIC master control (48 MHz External Clock)
Interface

Motionnet

RS-485 with transformer isolation

Half duplex communication

2.5/5/10/20 Mbps transmission rate can be set by soft-
ware (20 Mbps default)
 HSL
 RS-485 with transformer isolation

Full duplex communication

3/6/12 Mbps transmission rate can be set by software 
(6 Mbps default)
Connector

RJ45 connector x 4 (MRJ45 connector for Motionnet,
HRJ45 connector for HSL)
Interrupt

Status read back

Timer
LED Indicato

Link status (Red for Motionnet Link status, Green for HSL
Link status)
Dimensions
 122 (L) x 107 (W) mm
