HSL Slave Modules 51
PCI-7856
User’s Manual
Example 2
Provided you installed two HSL-DI16DO16-UJ, one
HSLDI16DO16-M-NN, two HSL-DO32-M-N and one HSL-
AI16AO2-VV with all slave modules in full duplex mode, you can
have the following conditions:
Condition 1
The HSL-AI16AO2-VV module operates in 6 Mbps.
We recommended that you use the provided slave index configu-
ration.
The scan time needs 30.33 µ x 17 at 6 Mbps, full duplex mode.
You can connect these modules with one master controller.
Condition 2
An HSL-AI16AO2-VV module operates at 12 Mbps.
We recommended that you use the provided slave index configu-
ration.
Item DIP Switch Index Occupation in HSL
HSL-DO32-M-N #1 1 1, 2
HSL-DO32-M-N #2 3 3, 4
HSL-AI16AO2M-VV 5 5, 6
HSL-DI16DO16-UJ #1 7 7
HSL-DI16DO16-UJ #2 8 8
HSL-DI16DO16-M-NN 9 9
Group 1 DIP Switch Index Occupation in HSL
HSL-DO32-M-N #1 1 1, 2
HSL-DO32-M-N #2 3 3, 4
HSL-DI16-UJ #1 5 5
HSL-DI16-UJ #2 6 6
HSL-DI16DO16-M-NN 7 7
