62 MotionCreatorPro 2
PCI-7856 
User’s Manual
C. Operation buttons and setting for 3 modes. You can
switch operation between relative, absolute and velocity
modes. The parameters of each mode must be set
before operations such as position 1 and 2, forward/
backward distance and forward/backward velocity.
Remember to set MaxVel before executing relative and
absolute mode. When using jog mode, the other three
modes will be disabled.
D. Motion status, I/O status and interrupt status display
area.
