HSL Slave Modules 49
PCI-7856
User’s Manual
The following examples are provided for user reference. All mod-
ules used are set in full duplex mode.
Example 1
Provided you installed two HSL-DI16DO16-UD, two HSL-DI32-
MN, and an HSL-AI16AO2-VV with all slave modules in full duplex
mode, you can have two conditions as follows:
Condition 1
HSL-AI16AO2-VV×1 is in 6 Mbps.
ADLINK suggests users can have the slave index configuration as
follows.
This is an example of a compact composition. The scan time
needs 30.33 µs x 8 at 6 Mbps, full duplex mode. Users can con-
nect the modules with one master controller.
Item DIP Switch Index Occupation in HSL
HSL-DI32-M-N #1 1 1, 2
HSL-DI32-M-N #2 3 3, 4
HSL-AI16AO2-VV 5 5, 7
HSL-DI16DO16-UD #1 6 6
HSL-DI16DO16-UD #2 8 8
