4.1.2 Analog I/O Module
ADLINK provides an M series as follows.
The selection guide is as follows.
Series Model Analog Input Analog Output Slave Index Occupation
M HSL-AI16AO2-M-VV 16 2 2 (Leap number)
HSL-AI16AO2-M-AV 16 2 2 (Leap number)
U HSL-AO4 4 2
Table 4-3: HSL Analog I/O Module Series
HSL - AI
□
AO
□
-
□
- XY
Discrete I/O Type:
 AI16AO16: 16 analog
inputs and 2 analog out-
puts
Series:
 M: Daughter board
with aluminum
cover
Signal Type:
 X: Input signal type,
V means voltage
and A means cur-
rent.
 Y: Output signal
type, V means volt-
age.
Table 4-4: HSL Analog I/O Module Selection Guide
