www.desatech.com 116035-01E 51
KEY
NO.
PART NO. DESCRIPTION QTY.
1 116719-01 Gas Valve Wire Harness (MV/PV) • • • • 1
116719-0 Gas Valve Wire Harness (MV) • • • • 1
3 116719-03 Gas Valve Wire Harness (PV) • • • • 1
4 116316-01 Ignition Module Bracket • • • • 1
5 114886-01 Door Retainer Bracket • • • • 1
6 111059-03 Ground Wire Harness • • • • 1
7 11086-01 Ignition Module Synetek • • • • 1
8 108863-01 Plug 4” Supply Connect • • • • 1
9 108867-01 Pilot Orifice BL14LP • • 1
108867-0 Pilot Orifice BL22N • • 1
10 108866-01 Pilot Assembly PSE • • 1
108866-0 Pilot Assembly PSE • • 1
11 706 Burner Orifice #44 • • 1
648 Burner Orifice #55 • • 1
1 6808 Valve Bracket • • • • 1
13 4389 Tube 3/8" Dia. x 11" Aluminum • • • • 1
14 4360 Pilot Bracket • • • • 1
15 14569 Gas Control Valve Millivolt • • 1
14570 Gas Control Valve Millivolt • • 1
16 14500 Fitting 3/8" MPT x 1/” Flare • • • • 1
17 14399 Fitting Brass Elbow 3/8" MPT x 3/8" Comp. Tube • • • • 1
18 14396 Fitting Brass Straight 3/8" MPT x 3/8” Comp. Tube • • • • 1
19 1499 Air Shutter • • • • 1
0 1419 Transformer, 4V Class • • • • 1
1 11404 Cable, Tie 8.5” #10 Screwdown • • • • 1
116 Washer, Flat 7/8" ID x " OD x 1/8" Thick • • • •
3 1114 Fitting Bulkead w/ Nut Brass • • • • 1
4 1101 Nut, #8-32 Hex Zinc • • • • 4
5 11186 Screw, #8-32 x 1” PPH • • • •
6 11187 Screw, #8 x 1/4" PPH • • • • 1
7 11109 Screw, #8-32 x 1/2” PPH • • • •
8 11107 Screw, #10-32 x 1/4" PPH Zinc • • • • 4
9 11105 Screw, #10 x 1/2" HWH LGM Zinc • • • • 11
30 1110 Screw, #8 x 3/8" PPH F Zinc. • • • •
PARTS LIST
BURNER ASSEMBLY FOR MODELS (v)CD36RNE, (v)CD36TNE,
(v)CD36RPE, (v)CD36TPE
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 44 of this manual.
(v
)CD36RNE
(v
)CD36TNE
(v
)CD36RPE
(v
)CD36TNE
