SuperDVR & QSDT8PCRC
User Manual
16
4
Main Display Interface
Run the SuperDVR program and the main display appears as shown below:
Figure4-1 SuperDVR Main Display Interface
4.1 Display Control Panel
4.1.1 Display Control Panel
Figure4-2 Display Control Panel
Display control panel includes Display Mode buttons, disk free space indicator,
and ‘
Auto Dwell’ button. Every button has its built-in indicator light. When you
switch the buttons on and off, the relative indicator lights turn on and off to
indicate the working status.
NOTICE: Users can tell which buttons are working by the color of
the buttons.
4.1.2 Display Modes
Figure4-3 Display Modes Panel
4.1.3 Flip Pages
When the display mode is 1CH, 4CH, 9CH, 16CH, click , system will
display the next window according to the display mode.
