OPERATING YOUR GAS RANGE
Before operating the unit, read this section thoroughly. The first time
the burners are operated, a small amount of smoke may be
generated due to burning of grease on the burners, especially on
oven and broiler burners. This is not dangerous. For that reason, it is
advisable to operate the burners without any cooking purpose for 10
minutes. This range is equipped with an electric ignition system to
ignite the burners. Therefore, it must be supplied with electricity.
If any electric power failure occurs, using a match can ignite the burners.
A constant supply of air is needed for combustion. Therefore, allow sufficient
ventilation into the room where the range is placed.
Manual Lighting of the oven burner during power outage
You should place a lighted match next to the entrance of the burner hole.
Depress the oven burner knob and turn counterclockwise.
Keep the control knob depressed for 10 seconds after lighting.
Check that the burner is lit (Figure 7),
> Operation of Surface Burners
There are 3 different types of surface burners with
different size and heat output on the cook top.
* A rapid burner (Front Right)
* Two semi-rapid burners (Back)
* A simmer burner (Front Left)
A WARNING-i
DO NOT ATTEMPT TO OPERATE ANY
SURFACE BURNER WITHOUT INSTALLING
IT. OTHERWISE, THERE IS A RISK OF
EXPLOSION.
First, they must be installed correctly, as seen in Figure 6.
The ring and its cap must be in its place. The burners should be level with the surface of
• The cookware supports must be in place on the cooktop.
These plastic rings are already in place and are used to
prevent rocking as shown in Figure 8.'Extra rings are
supplied for your convenience. Use stable cookware with a
flat bottom and always place the utensil on the cookware
supports before lighting the burner.
• The surface burners are controlled by knobs located on
control panel at front side of the appliance, as seen in ____________________________________
Figure 9. 1
Fiii. 8
