Space Requirements
Ç.9 bi ne [_dime n si on s/requ i re ments
18" min.
clearance upper
cabinet to
countertop
13"max. upper'
cabinet dept
"A"niln opening'"^
"В"орепПтд
j^-^width
For minimum
clearance to top of
cooktop, see Note
Conbet □ qiKilifled
Пост cmering irublter
b check that the Floor
covering can wilfuland
ol locut 90'F obovo room
temperature
tJie on insulated pad
or l/4‘ p^ood
under range, II installing
range over carpeting.
5" min' '
countertoff'’^
space to side
watt or other
combustible
material
к
¡Contour tino 1er
|bick sMool the
¡modo) 20" r»ngo
MODEL DIM. "A" DIM. "B" DIM. “C"
36" 36" 36 3/16” 28 3/16”
30" 30" . 30 3/16" 22 3/16"
20" 20" 20 1/4" 12 1/4"
Do not pinch the power
supply cord between the
range and the wall
Do not seal the range
to the side cabinets
Oven side panels must
extend beyond cabinet
fronts by 1.'4" where 0”
(flush) of side
walils desired
This shaded area recommended 24" min. when bottom
for installation of ripid qos pipe, metal cabinet is
Jexi^a flos pipe and aiectncoi pfotgeted by not less
ouriet ■(,'4" flame retardant
millboard covered with not
less than N0.28 MSG sheet
steel, 0.015" stainless steel,
0.024" aluminum or 0,020"
copper.
30" min. clearance between
the top of the cooking
platform and the bottom of an
unprotected wood or metal
cabinet.
Gas Requirements
TYPICAL CONNECTIONS
FLEXIBLE CONNECTOR HOOK UP RIGID PIPE HOOK UP
PRESSURE
REGULATOR
ADAPTER
^*n GAS FLOW
FLEX CONNECTOR-
ADAPTER
GAS SHUT OFF VALVE
Electrical Requirements
|Т|->к
120VOLT, 60HZ, 15 AMP MINIMUM
^ /-Х a
‘fl
!
i
i
