Rear Cover

Seat

Hex Bolt (E)

Lock Washer (F)

Flat Washer (G)

Place the seat over cover and fasten with four

■ hex bolts (E), lock washers (F) and flat

washers (G). See figure 4.

FIGURE 4.

STEERING WHEEL ASSEMBLY
(See figures 5, 6 and 7)

NOTE

Due to vibration during shipment, it
is possible that the steering shaft

on your unit may have dropped to a

position where alignment of parts is

difficuit. This must be kept in mind
during the assembly operation.

1. Check the upper and iower hex bearings. Be

sure they are seated and in position.

2. Place your hand under the front of the unit and

push up on the steering shaft assembly.

-3. Hold up the shaft assembly. Place the steer

ing tube assembly (L) on the shaft and start

the hex bolt (I) through the hole. See figure 5.

4. Fasten the tubing assembly to the steering

shaft assembly with hex bolt (I) and hex lock

nut (J) provided.

FIGURE 5.
