131-410A PARTS LIST FOR DECK AND BELT SYSTEM
MODEL 131-410A
zF. PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 _ Engine 30 710-0198 Hex Sems Bolt 5/16-18 x .75"
2 714-0104 Hairpin Cotter Lg.*
3 736-0264 Fi-Wash. 31 12139 —456 Deck Lift Shaft Ass’y.
4 09785 Variable Speed Brkt. Ass’y- 32 712-0158 Hex Cent. L-Nut 5/16-18 Thd.
5 747-0316 Ciutch Rod 33 736-0116 FI-Wash. .635 I.D. x .93" O.D.
6 712-0798 Hex Nut 3/8-16 Thd.* 34 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
7 736-0217 L-Wash. 3/8" I.D. (Heavy 35 732-0192 Spring .88" O.D. x 3.75" Lg.
Duty) (Var. Drive)
8 747-0125 Handie Lift Rod 3/8" Dia. 36 736-0119 L-Wash. 5/16" I.D.*
9 14362 Deck Lift & Float Brkt. Ass’y. N 37 712-0267 Hex Nut 5/16-18 Thd.*
10 720-0143 Grip—Black 38 714-0365 #6 Hi-Pro Key 5/32" x 5/8"
11 14374 Deck Lift Handle Ass’y. N Dia.
12 12150 —456 Index and Support Brkt. 39 09780 Transmission Belt Guard
13 714-0507 Cotter Pin 3/32" Dia. x .75" Ass’y.
Lg.* 40 747-0360 Belt Guard Ass’y. N
14 735-0126 Rubber Wash. .33" I.D. x .87" 41 712-0267 Hex Nut 5/16-18 Thd.*
O.D. 42 736-0119 L-Wash. 5/16" I.D.*
15 736-0101 FI-Wash. .406" I.D. x 1.0" 43 10423 Engine Belt Guard Ass’y.
O.D. 44 710-0198 Hex Sems Bolt 5/16-18 x .75"
16 712-0116 Hex Ins. L-Nut 3/8-24 Thd. Lg.*
17 726-0221 Push Cap 1/2" Dia. 45 711-0404 Shoulder Nut
18 731-0142 Foot Pedal—Bar Grip 46 714-0129 #4 Hi-Pro Key 3/32" X 5/8"
19 12133 Clutch Pedal Ass’y. Dia.
20 747-0368 Deck Lift Rod 3/8" Dia. N 47 10247 Transmission Plate
21 712-0267 Hex Nut 5/16-18 Thd.* 48 717-0223 Transmission Ass’y.—Comp.
22 736-0119 L-Wash. 5/16" I.D.* 49 710-0322 Hex Sems Bolt 5/16-18 x
732-0233 Tension Spring 1.00" Lg.*
^4 726-0109 Push Cap 5/16" Dia. 50 741-0139 Ball Bearing .50" I.D. x 1.30"
25 12419 Clutch Pedal Lockout Rod O.D.
26 10173 Variable Speed Guide Brkt. 51 750-0146 Spacer .520" I.D. x .692" O.D
Ass’y. 52 748-0181 Moveable Sheave Ass’y.
27 14335 —456 Main Frame 53 715-0124 Spring Pin Spir. 5/32" Dia. x
28 711-0677 Adjustment Ferrule .62" Lg.
29 747-0364 Deck Adjustment Hanger 54 710-0442 Hex Bolt 5/16-18 X 1.50" Lg.*
Rod N 55 711-0392 Adjustment Ferrule
'For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
(456—Radiant Tangerine) When ordering parts if color or finish is important, use color code shown at left. (e.g. Radiant
Tangerine Finish—12175 (456).)
31
