ASSEMBLY INSTRUCTIONS

NOTE

This unit is shipped WITHOUT GAS

OLINE or OIL. After assembly, see
separate engine manual for proper
fuel and engine oil recommenda
tions.

■IGNOTE

Reference to right hand or left hand

side of machine is from the driver’s
seat facing forward.

-Contents of Hardware Pack:

FIGURE 1.

A (2)

B (1)

C (1)
D (1)
E

G (4)

H (2)
I (1)

J (1)

(

)

(4)
(4)

Ignition Keys
Steering Wheel Cap
Hex Lock Nut

Belleville Washer
Hex Bolts 5/16-18

5/8" Long

Lock Washers 5/16" I.D.

Flat Washers

Truss Screws

Hex Bolt

1/4-20 X

1.25" Long

Hex Lock Nut V4-20 Thread
Battery Strap (Not Shown)

-Loose Parts in Carton:

K (1) Steering Cover

L (1) Steering Tube Assembly
M (1) Seat
N (1) Battery Pack

P (1) Steering Wheel

SEAT ASSEMBLY

—1. Release the rear cover latch and raise the rear

cover. See figure 3.
