131-41 OA
PARTS LIST FOR MAIN BODY MODEL 131-410A
REF.
NO.
PART 1 COLOR
NO. 1 CODE
DESCRIPTION
NEW
PART
1 757-0265 Seat Complete
2 710-0289 Hex Bolt 1/4-20 X .50" Lg.*
3 12144 Latch—Engine Cover
4 710-0456 Hex Drilling Scr. #10 x .50"
Lg.
5 13912 Support Bracket
6 712-0526 Speed Nut #10-24 Thd.
7 731-0262 Steering Column Cover
8 710-0473 Truss Mach. Scr. #10-24 x
.50" Lg.*
9 712-0287 Hex Nut 1/4-20 Thd.*
10 736-0329 L-Wash. 1/4" I.D.*
11 710-0456 Hex Drilling Scr. #10 x .50"
Lg.
12 725-0464 Ignition Switch
13 723-0241 Foot Pad
14 710-0227 Hex Wash. Hd. AB-Tap Scr.
#8 X .50" Lg.
15 712-0107 Hex Cent. L-Nut V4-20 Thd.
16 14361 Speed Control Stop Brkt. N
17 736-0105 Bell-Wash. 3/8" I.D.
18 738-0255 Shoulder Bolt .375 Dia. x .36
(1/4-20 Thd.)
19 731-0189 Knob—Black
20 12175 —456 Cover Plate
21 710-0252 Hex Bolt 1/4-20 x .75" Lg.*
22 12128 —456 Floor Pan
23 746-0429 Throttle Control Ass’y.
Comp. N
24 12150 —456 Index and Support Brkt.
25 12125 —456 Main Frame
26 710-0198 Hex Sems Bolt 5/16-18 x .75"
Lg.‘
27 712-0158 Hex Cent. L-Nut 5/16-18 Thd.
28 14374 Deck Lift Handle Ass’y. N
29 720-0143 Grip—Black
30 723-0241 Foot Pad
31 736-0225 Int. L-Wash. 5/8" I.D.
32 736-0119 L-Wash. 5/16" I.D.*
33 712-0267 Hex Nut 5/16-18 Thd.*
34 725-0201 Ignition Keys
35 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
36 732-0118 Extension Spring
37 12132 —456 Cover Ass’y.
38 738-0155 Shoulder Bolt .437 Dia. x
.162" Lg.
•For faster service obtain standard nuts, boits and washers iocaily. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
(456—Radiant Tangerine) When ordering parts if color or finish is important, use color code shown at left. (e.g. Radiant
Tangerine Finish—12175 (456).)
NOTE; The engine is not under warranty by
the mower manufacturer ... If repairs or
service is needed on the engine, please
contact your nearest author­
ized engine service outlet.
Check the "Yellow Pages" of
your telephone book under
“Engines—Gasoline.”
Find It Fast
In the
Yellow Pages
NOTE
This instruction manual covers various models
and all specifications shown do not necessari­
ly apply to your model. Specifications subject
to change without notice or obligation.
27
