131-410A PARTS LIST FOR DECK AND BELT SYSTEM
MODEL 131-410A
,0.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION NEW
PART
1 754-0251 Deck “V”-Belt Vz" x 51.24" 35 712-0287 Hex Nut 1/4-20 Thd.*
Lg. 36 736-0329 L-Wash. 1/4" I.D.*
2 712-0116 Hex Ins. L-Nut 3/8-24 Thd. 37 736-0119 L-Wash. 5/16" I.D.*
3 15224 Deck idler Brkt. Ass’y- 38 738-0141 ShId. Bolt .437" Dia. x .350
4 712-0267 Hex Nut 5/16-18 Thd.* 39 712-0267 Hex Nut 5/16-18 Thd.*
5 736-0231 FI-Wash. .344" I.D. x 1.12" 40 732-0308 Ext. Spring .50" O.D. x 6.37"
O.D. Lg.
6 732-0400 Ext. Spring .62" O.D. x 3.06" 41 710-0376 Hex Bolt 5/16-18 X 1.0" Lg.*
Lg. 42 736-0119 L-Wash. 5/16" I.D.*
7 750-0258 Spacer .315" i.D. x .75" O.D. 43 712-0267 Hex Nut 5/16-18 Thd.*
X .37 44 14371 30" Deck Ass’y. N
8 710-0118 Hex Boit 5/16-18 X .75" Lg.* 45 712-0287 Hex Nut 1/4-20 Thd.*
9 10426 Belt Keeper Ass’y. 46 736-0329 L-Wash. 1/4" I.D.*
10 710-0258 Hex Bolt 1/4-20 X .62" Lg.* 47 732-0370 Torsion Spring
11 725-0269 Safety Switch—N.C. 48 710-0134 Carr. Bolt 1/4-20 X .62" Lg.*
12 15076 Spindie Mtg. Brkt. Ass’y. 49 726-0106 Push Nut
1
/
4
" Rod
13 714-0507 Cotter Pin 3/32" Dia. x .75" 50 710-0134 Carr. Bolt 1 / 4-20 X .62" Lg.*
Lg.* 51 15198 Chute Deflector Ass’y.
14
—
Part of Ref. No. 17 Comp.
15 14366 Deck Engagement Handle 52 15192 Deflector Hinge Brkt.
Ass’y. N 53 747-0303 Hinge Pin
16 720-0143 Grip—Black 54 736-0329 L-Wash.
1
/
4
" I.D.*
17 725-0268 Safety Switch—N.O. 55 712-0287 Hex Nut
1
/
4-20
Thd.*
18 710-0599 Hex Wash. Hd. Seif-Tap Scr. 56 15226 Deck Hinge Brkt.
1/4-20 X .50" Lg. 57 10438 Var. Spd. Pulley Ass’y.
19 747-0366 Deck Stabilizer Rod 3/8" Dia. 12168 Var. Spd. Pulley and Brkt.
X 8.8" Lg. N Ass’y.—Comp.
712-0267 Hex Nut 5/16-18 Thd.* 58 736-0921 L-Wash. 1 / 2 " I.D.*
1 736-0119 L-Wash. 5/16" I.D.* 59 712-0384 Hex Cent. L-Nut 1 / 2 -I 3 Thd.
22 710-0118 Hex Bolt 5/16-18 X .75" Lg.* 60 711-0572 Step Wash. (For Engine
23 741-0211 Blade Spindle Pulley)
24 736-0119 L-Wash. 5/16" I.D.* 61 736-0217 L-Wash. 3/8" I.D. (Heavy
25 712-0267 Hex Nut 5/16-18 Thd.* Duty)
26 753-0210 Kit—Blade Adapter Ass’y. 62 710-0331 Hex Bolt 3/8-24 x 2.25" Lg.*
27 710-0117 Hex Bolt 5/16-24 x 1.00" Lg. 63 712-0922 Hex Jam Nut 1 / 2-20 Thd.
(Grade 5) 64 736-0921 L-Wash. 1 / 2 " I.D.*
28 710-0180 Hex Bolt 3/8-24 x .75" Lg. 65 754-0136 Transmission “V”-Belt 21/32"
(Grade 5) X 31" Lg.
29 736-0217 L-Wash. 3/8" I.D. (Heavy 66 756-0174 Transmission Pulley .50" I.D.
Duty) 67 756-0378 Engine Two-Step Pulley N
30 742-0193 30" Blade 68 754-0187 Engine Drive “V”-Belt 21/32"
31 736-0119 L-Wash. 5/16" I.D.* X 24" Lg.
32
—
Order Ref. No. 26 69 756-0291 Pulley 7.00" O.D.
33 712-0123 Hex Nut 5/16-24 Thd.* 70 12153 Front Deck Brkt.
34 12724 Bearing Housing 71 756-0116 Idler Pulley
*For faster service obtain standard nuts, bolts and washers iocaiiy. if these items cannot be obtained iocaily, order by part
number and size as shown on parts list.
(456—Radiant Tangerine) When ordering parts if color or finish is important, use coior code shown at left. (e.g. Radiant
Tangerine Finish—12175 (456).)
33
