Appendix 2 — Electrical Data
QUIETPACT™ 75D Recreational Vehicle Generator
Electrical Schematic - 120/240 VAC Output- Drawing No. D2792-A
LEGEND
AVR -AUTOMATIC VOLTAGE REGULATOR
BCR -BATTERY CHARGE RECTIFIER
BOW -BATTERY CHARGER
CB1 -CIRCUIT BREAKER 35A
CB2 -CIRCUIT BREAKER (4A)
D1 -DIODE 600V, 6AMP
D2 -DIODE 600V, 6AMP
DPE -EXCITATION WINDING
FI -FUSE 14AMP SFE
FS -FUEL SOLENOID
FP -FUEL PUMP
CP -GLOW PLUGS
HM -HOURMETER
HWT -HIGH WATER TEMP SWITCH
LOS -LOW OIL PRESSURE SWITCH
PHC -PREHEAT CONTACTOR
R1 -RESISTOR, 1 OHM, 25W
R2 -RESISTOR, 20 OHM. 12W
S -STARTER
SC -START CONTACTOR
SW -PREHEAT SWITCH
SW1 -SWITCH, START/STOP
