Technical Summary
Setting Up the PCI-SC200
There are two jumper settings you may need to make on the card
to set it up. One setting assigns the PCI INT interrupt, the other sets
the card's termination.
Setting the INT Assignment
As explained in Chapter 2, any PCI card you install must use PCI
INT A. On the PCI-SC200, you assign the INT by setting jumper JPl
or JP2. The default setting for the card already is INT A, so you do
not need to change the setting to use the SC-200 with this mainboard.
The INT assignment jumper settings are illustrated below. The
settings are printed on the card for your convenience.
JPl & 2: Interrupt settings
INT A
(default)
-
-
-
-
-
C)
CM
«—
Q_ Q_
(_)
CM
*—
Q- Q-
o
$
CM
•—
Q- O-
o' o'
(
1
)
o
o
c;)
o
$
o
u
o
(j
o
(!)
INTB
INTO
CNI
O-
INTO
4 - 1 5
