P/I-P55SP4

User's Manual

Chipset Features Setup

This screen controls the settings for the board's chip set. Naviga­

tion and controls for this screen are the same as for the previous
screen.

Chipset Features Screen

ROM PCI/ISA BIOSÎPI-55SP4:

CHIPSET FEATURES SETUP

AWARD SOFTWARE INC.

Auto Configuration

L2 (WB) Tag Bit Length

Async SRAM Leadoff

Async SRAM Burst Timing

FP CAS Precharge

RAS To CAS delay time

FP RAS Precharge time

RAS active when refresh
CAS delay in post-write

EDO CAS pulse Width
EDO CAS Precharge time

EDO RAS Precharge time

L2 Cache Update Mode

Next Address (NA#)

CPU to PCI Burst Write

CPU to PCI Post Write
CPU-PCI Post Write Rate

Snoop PCI Master Write
Snoop PCI Master Read
Slow Refresh (1:4)

Enabled

7bits
3/4
2T

IT

3T

3T
4T

IT

R1/W2

IT

3T

WB

Disabled

Disabled

Enabled
4T

Enabled
Enabled

Disabled

ISA Bus Clock Frequency
16-bit ISA Wait State
16-bit I/O Recory Time

8-bit I/O Recory Time

Video BIOS Cacheable

Allocate Memory Hole

Hole Start Address

Hole Size

PCICLK/4

1 Wait

5 BUSCLK
8 BUSCLK

Disabled

Disabled

OFCOOOOH

256KB

ESC

FI

F5

F6
F7

Quit

Ti—H— : Select Item

Help

PU/PD/+/-

: Modify

Old Values (SHIFT)F2 : Color

Load BIOS Defaults

Load Setup Defaults

3 - 1 2
