P/I-P55SP4
User’s Manual
IDE HDD Auto E>etection.......................................................... 3-25
Save And Exit Setup.....................................................................3-27
Exit Without Saving..................................................................... 3-27
NCR SCSI BIOS & Drivers................................................................ 3-28
. Flash Memory Writer Utility..............................................................3-29
Chapter 4: Technical Summary.................................4-1
Jumper Setting Summary.................................................................... 4-1
PS/2 Mouse Port Selector: JP5.......................................................4-1
SRAM Type Selector: JP6, JP7, JP8 & JP9..................................... 4-2
Level 2 Cache Size: JPIO & JPll.....................................................4-3
CPU External Clock Speed Selector: JP12, JP13 & JP14..............4-4
Flash Eprom Boot Block Write Selector: JP16.............................4-5
Flash Eprom Read/Write Selector: JP15...................................... 4-5
5-Volt/12-Volt EPROM Selector: JP17..........................................4-6
CPU Internal Clock Ext. Mulitple Selector: JP20 & JP21.... 4-6
Voltage Regulator Output Selector: JP22, JP23/JP28, JP29 4-7
Voltage Regulator Module Selector: JP32 - JP35......................... 4-7
Level 2 Cache Options................................................................... 4-8
External Connections......................................................................... 4-10
Port & Controller Cables........................... ................................. 4-12
Connecting A Power Supply...................................................... 4-13
The PCI-SC200 SCSI Interface Card.................................................4-14
Setting Up the PCI-SC200........................................................... 4-15
SCSI ID Numbers......................................................................... 4-18
IV
